| Article number: | 1017027124-GRN-S |
| Availability: | In stock |
DESCRIPTION
Whether it’s navigating asphalt or venturing through an unpaved short cut, the Avail AR is smooth on flats, spry on climbs and confident on descents.
KEY PERFORMANCE FACTORS
ComfortThe lightweight ALUXX aluminum frame features the latest endurance geometry with an Advanced-grade composite fork and D-Fuse seatpost to diminish vibrations. |
|
ControlThe 32c tires provide stability on both road and off-road surfaces, with compatibility for tubeless tires up to 38c. The OverDrive steerer and powerful disc brakes ensure precise handling and reliable stopping power, giving you confidence on any terrain. |
|
Carrying CapacityEquipped with frame mounts for racks and fenders, the Avail AR ensures you're ready for longer journeys with all the necessary gear and protection. |
FEATURES
 |
 |
 |
||
ALUXX Aluminum TechnologyThis Performance level frame material features 6061 alloy with single-butted tubes to produce strong, lightweight framesets for a variety of different bikes and riding styles. |
|
Compact Road DesignWhen introduced by Giant in 1990s, Compact Road revolutionized the look and feel of high-performance road bikes forever. A downward sloping toptube (from the headtube to the seattube) creates smaller front and rear triangles for a lighter, stiffer bike. It also makes it easier for riders of all sizes to have a perfect fit. |
|
D-Fuse SeatpostThe proprietary “D” shaped composite seatpost damps vibration, resulting in a smooth, compliant ride. |
 |
 |
|||
OverDriveDesigned to provide precise front-end steering performance, this fork steerer tube technology uses oversized headset bearings (1 1/4” lower and 1 1/8” upper for road, 1 1/2” lower and 1 1/8” upper for mountain) and tapered steerer tube work in conjunction to provide optimal steering stiffness. |
|
Tubeless SystemEngineered with proprietary Dynamic Balanced Lacing technology, this tubeless ready composite WheelSystem delivers superior efficiency, pinpoint control and comfort. |
|
SIZE GUIDE
Sizing to be used as a reference only. Please check with a local authorized dealer to determine the correct size.
Available sizes may vary from country to country.
| Sizes | Height |
| XXS | 4'9" - 5'1" |
| XS | 5'0" - 5'4" |
| S | 5'2" - 5'7" |
| M | 5'5" - 5'9" |
GEOMETRY
| XXS | XS | S | M | ||
|---|---|---|---|---|---|
| A | Seat Tube Length (inch) | 14.8 | 16.1 | 17.5 | 18.9 |
| B | Seat Tube Angle | 75.0° | 74.5° | 74.5° | 74.0° |
| C | Top Tube Length (inch) | 19.8 | 20.3 | 20.7 | 21.3 |
| D | Head Tube Length (inch) | 4.1 | 4.6 | 5.4 | 6.2 |
| E | Head Tube Angle | 70.0° | 70.5° | 71.5° | 72.0° |
| F | Fork Rake (inch) | 2.1 | 2.1 | 2.1 | 2.1 |
| G | Trail (inch) | 2.8 | 2.7 | 2.4 | 2.3 |
| H | Wheelbase (inch) | 39.1 | 39.3 | 39.4 | 39.6 |
| I | Chain Stay Length (inch) | 16.6 | 16.6 | 16.6 | 16.6 |
| J | Bottom Bracket Drop (inch) | 3.1 | 3.1 | 3.1 | 3.1 |
| K | Stack (inch) | 20.6 | 21.2 | 22.1 | 22.9 |
| L | Reach (inch) | 14.3 | 14.4 | 14.5 | 14.7 |
| M | Stand Over Height (inch) | 25.7 | 26.8 | 27.9 | 29 |
| N | Handlebar Width (inch) | 15 | 15 | 15.7 | 15.7 |
| O | Stem Length (inch) | 2.8 | 2.8 | 3.1 | 3.5 |
| P | Crank Length (inch) | 6.5 | 6.5 | 6.7 | 6.7 |
| Q | Wheel Size | 700C | 700C | 700C | 700C |
SPECIFICATIONS
| Sizes | XXS, XS, S, M |
| Colours | Mineral Green/Asphalt Green |
| Frame | ALUXX-grade aluminum, 12x142mm thru-axle, disc |
| Fork | Advanced-grade composite, full-composite OverDrive steerer, 12x100mm, disc |
| Shock | N/A |
| Handlebar | Liv Connect, 31.8mm XXS: 380mm, XS: 380mm, S: 400mm, M: 400mm, L: 420mm |
| Grips | Liv All Condition |
| Stem | Giant Sport XXS: 70mm, XS: 70mm, S: 80mm, M: 90mm, L: 90mm |
| Seatpost | Giant D-Fuse, alloy XXS: 300mm, XS: 300mm, S: 300mm, M: 350mm, L: 350mm |
| Saddle | Liv Approach |
| Shifters | Shimano Claris |
| Front Derailleur | Shimano Claris |
| Rear Derailleur | Shimano Claris |
| Brakes | Tektro MD-C550 mechanical, Tektro rotors [F]160mm, [R]160mm |
| Brake Levers | Shimano Claris |
| Cassette | Shimano CS-HG50, 8-speed, 11x34 |
| Chain | KMC Z83 |
| Crankset | FSA Tempo, 34/50 XXS: 165mm, XS: 165mm, S: 170mm, M: 170mm, L: 172.5mm |
| Bottom Bracket | cartridge |
| Rims | Giant S-R2 Disc wheelset |
| Hubs | Giant alloy, 12mm thru-axle |
| Spokes | stainless |
| Tires | Giant S-R3 AC, 700x32c |
| Extras | 38mm max tire size |
| Weight | The most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality. |
