| Article number: | 1030002197-BLK-L |
| Availability: | In stock |
FEATURES
 |
||||
ALUXX Aluminum TechnologyThis Performance level frame material features 6061 alloy with single-butted tubes to produce strong, lightweight framesets for a variety of different bikes and riding styles. |
|
SIZE GUIDE
Sizing to be used as a reference only. Please check with a local authorized dealer to determine the correct size.
Available sizes may vary from country to country.
| Sizes | Height |
| S | 5'3" - 5'7" |
| M | 5'7" - 5'11" |
| L | 5'11" - 6'3" |
| XL | 6'3" - 6'7" |
GEOMETRY
| S | M | L | XL | ||
|---|---|---|---|---|---|
| A | Seat Tube Length (inch) | 15.2 | 17.1 | 19.1 | 21.1 |
| B | Seat Tube Angle | 73.0° | 73.0° | 72.5° | 72.5° |
| C | Top Tube Length (inch) | 22.4 | 23 | 23.6 | 24.2 |
| D | Head Tube Length (inch) | 5.1 | 5.7 | 6.3 | 6.9 |
| E | Head Tube Angle | 70.5° | 70.5° | 70.5° | 70.5° |
| F | Fork Rake (inch) | 1.7 | 1.7 | 1.7 | 1.7 |
| G | Trail (inch) | 3.3 | 3.3 | 3.3 | 3.3 |
| H | Wheelbase (inch) | 42.9 | 43.5 | 44.1 | 44.8 |
| I | Chain Stay Length (inch) | 18.3 | 18.3 | 18.3 | 18.3 |
| J | Bottom Bracket Drop (inch) | 2.6 | 2.6 | 2.6 | 2.6 |
| K | Stack (inch) | 24.3 | 24.8 | 25.4 | 25.9 |
| L | Reach (inch) | 15 | 15.4 | 15.6 | 16 |
| M | Stand Over Height (inch) | 28.3 | 29.4 | 30.8 | 32.3 |
| N | Handlebar Width (inch) | 25.2 | 26.8 | 26.8 | 26.8 |
| O | Stem Length (inch) | 3.1 | 3.1 | 3.5 | 3.5 |
| P | Crank Length (inch) | 6.7 | 6.9 | 6.9 | 6.9 |
| Q | Wheel Size | 700C | 700C | 700C | 700C |
SPECIFICATIONS
| Sizes | S, M, L, XL |
| Colours | T/K |
| Frame | ALUXX-grade aluminum |
| Fork |
SR Suntour NEX, 63mm travel
|
| Shock | N/A |
| Handlebar |
alloy, mid-rise, 25.4mm S:64cm, M:64cm, L:68cm, XL:68cm
|
| Grips | Giant ErgoContact |
| Stem | alloy, quill, 25.4mm, adjustable S:90mm, M:90mm, L:110mm, XL:110mm |
| Seatpost | alloy suspension, 30.9mm S:300mm, M:300mm, L:350mm, XL:350mm |
| Saddle | Giant ErgoContact |
| Pedals |
fitness platform
|
| Shifters | microSHIFT Advent, 1x9 |
| Front Derailleur | N/A |
| Rear Derailleur | microSHIFT Advent |
| Brakes | Tektro hydraulic [F]160mm, [R]160mm rotors |
| Brake Levers | Tektro TKD143 |
| Cassette | microSHIFT Advent, 11x46 |
| Chain |
KMC X9
|
| Crankset | forged alloy, 40t S:170mm, M:170mm, L:175mm, XL:175mm |
| Bottom Bracket | sealed cartridge |
| Rims | Giant double-wall aluminum |
| Hubs | alloy, 32h |
| Spokes | stainless, 14g |
| Tires | Innova Multi Purpose Hybrid, anti puncture, 700x45c |
| Extras | 55mm max tire size |
| Weight | The most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality. |
