| Article number: | 1089005105-PAN-M |
| Availability: | In stock |
FEATURES
 |
 |
 |
||
ALUXX Aluminum TechnologyThis Performance level frame material features 6061 alloy with single-butted tubes to produce strong, lightweight framesets for a variety of different bikes and riding styles. |
|
FlexPoint Suspension TechnologyA proven “single-pivot” design that uses the flexing action of the chainstay/seatstay junction to produce a lightweight and durable suspension system with 4.7 inches/120mm of rear travel. |
|
OverDriveGiant’s original oversized fork steerer tube technology. Designed to provide precise front-end steering performance, the system’s oversized headset bearings (1 1/4” lower and 1 1/8” upper for road, 1 1/2” lower and 1 1/8” upper for mountain) and tapered steerer tube work in conjunction to provide optimal steering stiffness. |
|
|
|
 |
|
|
PowerCoreA massively oversized bottom-bracket/chainstay area features a fully integrated, 86-millimeter wide bottom-bracket design (92-millimeter wide for off-road bikes). Asymmetric chainstays provide additional stiffness on the driveside and stability on the non-driveside. |
|
Tubeless SystemFewer flat tires. Greater traction. Less rolling resistance and a smoother, faster ride. Giant’s Tubeless System makes it easier than ever to experience all these benefits. |
|
|
SIZE GUIDE
Sizing to be used as a reference only. Please check with a local authorized dealer to determine the correct size.
Available sizes may vary from country to country.
| Sizes | Height |
| M | 5'7" - 5'11" |
| L | 5'10" - 6'2" |
| XL | 6'2" - 6'6" |
GEOMETRY
| M | L | XL | ||
|---|---|---|---|---|
| A | Seat Tube Length (inch) | 16.7 | 17.7 | 18.7 |
| A1 | Seat Post Insertion Depth (inch) | 9.5 | 10.6 | 11.5 |
| B | Seat Tube Angle | 76.5° | 76.5° | 76.5° |
| C | Top Tube Length (inch) | 23.4 | 24.5 | 25.7 |
| D | Head Tube Length (inch) | 4.3 | 4.7 | 4.9 |
| E | Head Tube Angle | 65.5° | 65.5° | 65.5° |
| F | Fork Rake (inch) | 1.7 | 1.7 | 1.7 |
| G | Trail (inch) | 4.9 | 4.9 | 4.9 |
| H | Wheelbase (inch) | 47.2 | 48.3 | 49.6 |
| I | Chain Stay Length (inch) | 17.3 | 17.3 | 17.3 |
| J | Bottom Bracket Drop (inch) | 1.6 | 1.6 | 1.6 |
| K | Stack (inch) | 24.5 | 24.9 | 25 |
| L | Reach (inch) | 17.5 | 18.5 | 19.7 |
| M | Stand Over Height (inch) | 28.9 | 29.6 | 29.8 |
| N | Handlebar Width (inch) | 30.7 | 30.7 | 30.7 |
| O | Stem Length (inch) | 1.6 | 2 | 2 |
| P | Crank Length (inch) | 6.7 | 6.7 | 6.7 |
| Q | Wheel Size | [F] 29" [R | [F] 29" [R | [F] 29" [R |
SPECIFICATIONS
| Sizes | S, M, L, XL |
| Colours | Copper Coin, Panther |
| Frame | ALUXX-grade aluminum, 125mm FlexPoint suspension, 12x148mm thru-axle |
| Fork | Crest 34 SL RCL, 140mm, Boost 15x110 QR |
| Shock | Suntour Raidon R, 190x45 |
| Handlebar | Giant Contact SL TR35, 780x35mm |
| Grips | Giant Sole-O |
| Stem | Giant Contact SL 35 S:40mm, M:40mm, L:50mm, XL:50mm |
| Seatpost | Giant Contact Switch AT dropper, remote S: 110-140mm travel / 30.9 x 395mm |
| Saddle | Giant Romero |
| Pedals | |
| Shifters | Shimano CUES SL-6000, 1x10 |
| Front Derailleur |
N/A
|
| Rear Derailleur | Shimano CUES RD-U6000 |
| Brakes | Shimano BR-MT420, hydraulic, Shimano RT-26 rotors [F]180mm, [R]180mm |
| Brake Levers |
Shimano MT-401
|
| Cassette | Shimano CUES, CS-LG300, 11x48 |
| Chain |
KMC X-11
|
| Crankset | Shimano CUES FC-U6000, 30t S:170mm, M:170mm, L:170mm, XL:170mm |
| Bottom Bracket | Shimano, threaded |
| Rims | Giant TRA 2 wheelset, 6061 alloy, hookless, 30mm inner width, 40mm outer width, 21mm height, Wide Guard Technology |
| Hubs | [F] Giant MTB alloy, six-bolt, [R] Giant MTB alloy, 72 POE (Points of Engagement), six-bolt, HG driver body |
| Spokes | Sapim, 28, J-bend |
| Tires |
[F] Maxxis Minion DHF 29x2.5 WT, EXO, TR [R] Maxxis Dissector 29x2.4 WT, Dual, EXO, TR, tubeless
|
| Extras | tubeless prepared, max tire size 2.4", max chainring size 32t |
| Weight | The most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality. |
