| Article number: | 2303350105-BLKD-M |
| Availability: | In stock |
DESCRIPTION
Ride trails with confidence, control and flat-out fun. This new E-bike has a powerful motor, plush suspension, and intuitive controls that can take your trail adventures to a whole new level.
KEY PERFORMANCE FACTORS
Powerful pedaling supportThe new compact SyncDrive Sport motor has Smart Assist technology and is sonically tuned for smooth, quiet performance. It delivers 75Nm of torque for high power, even at low speeds on technical trails. |
Confident handlingALUXX SL aluminum frame with 120mm travel FlexPoint rear suspension and larger diameter 29-inch wheels produces a smooth, stable ride on technical trails. |
Long-lasting funThe new EnergyPak offers ample range and the integrated battery pack makes charging quick and easy. |
RANGE
How far can I expect to ride on a single battery charge?
The range for a single battery charge can vary greatly depending on conditions such as the combined weight of the rider and cargo; wind resistance; tire pressure and tread profile; terrain and elevation changes; road or trail surface; outdoor temperature; maintenance of the E-Bike; and the condition of the battery.
The bar below gives an approximate range. Conditions are categorized as extreme, good and ideal. Extreme conditions typically occur when riding with a heavy load, strong headwinds or excessive climbs.
Energypak 500 / Syncdrive Sport
- Extreme: 45 km
- Good: 90 km
- Ideal: 180 km
HIGHLIGHTS
The SyncDrive Sport motor delivers 75Nm of torque for smooth acceleration and climbing power. FlexPoint rear suspension (125mm travel, plus 140mm up front) gobbles up rocks and other trail obstacles. The RideControl Dash control unit has integrated handlebar support buttons for improved ergonomic control. And a new EnergyPak battery system lets riders push their trail riding adventures farther.
Giant E-Bike Technologies
This integrated group of technologies forms the operating system of every Giant E-bike. The user-friendly components—including the motor, control unit and battery pack—function as part of an overarching system that seamlessly combines electric power with human power to produce a smart, natural and powerful ride experience.
Giant RideControl App
RideControl Dash wirelessly connects with the RideControl App, so your smartphone can function as a display for ride data and system updates.
FEATURES
 |
 |
 |
||
ALUXX SL Aluminum TechnologyThis High-Performance level, state-of-the-art aluminum material is made predominantly from 6011 alloy and delivers best-in-class strength-to-weight ratios. These framesets also feature unique welding technologies for a high-performance ride quality. |
|
FlexPoint Suspension TechnologyA proven “single-pivot” design that uses the flexing action of the chainstay/seatstay junction to produce a lightweight and durable suspension system with 4.7 inches/120mm of rear travel. |
|
Hybrid Cycling TechnologyHybrid Cycling Technology is a system that combines electric power with human power to produce a smart, natural and powerful E-bike riding experience. It’s an integrated group of technologies that includes our RideControl control unit, EnergyPak battery systems and SyncDrive motor. |
 |
 |
 |
||
SyncDrive SportInnovation, manufacturing expertise and a motor system powered by Yamaha all combine to expand any rider’s abilities. SyncDrive Sport offers three support modes and is equipped on E-bikes that are used for both everyday riding and for more demanding off-road riding. This small mid-drive motor delivers a massive maximum 70Nm of torque and is widely acclaimed for its performance and reliability |
|
Smart AssistAll SyncDrive motors have Smart Assist technology, which adjusts the support to match the rider’s needs. By using information from multiple sensors, both rider input and terrain feedback are used to determine the optimal amount of pedaling assistance. SyncDrive is the only e-bike system that utilizes both rider input and terrain feedback. It gives you a smooth, natural riding experience with ample power when you need it, while also conserving power when you don’t need as much. |
|
EnergyPak PlusThis range extender can boost total capacity by 250Wh. It has all the latest technologies combined with an up-to-date design that fits a select number of bikes. It has smart technology so it automatically turns on when your battery loses power, giving you peace of mind that you can reach your destination. |
 |
|
 |
|
|
EnergypakGiant’s latest EnergyPak battery systems feature streamlined designs that are integrated with the E-bike for a sleek and modern profile. Giant E-bikes offer several different EnergyPak options including the EnergyPak Smart and EnergyPak. Each one is designed to optimize the E-bike experience for a specific style of riding. |
|
RideControl DashThis two-in-one unit features buttons to control support modes plus an integrated color display. You can check range, battery level and support mode, along with standard cycling data such as speed and distance without having to another screen to the E-bike. It also has an ANT+ connection so you can connect a heart rate monitor and other fitness devices. |
|
|
SIZE GUIDE
Sizing to be used as a reference only. Please check with a local authorized dealer to determine the correct size.
Available sizes may vary from country to country.
| Sizes | Height |
| S | 5'4" - 5'8" |
| M | 5'7" - 5'11" |
| L | 5'10 - 6'2" |
| XL | 6'2" - 6'6" |
GEOMETRY
| S |
M |
L |
XL |
||
| A | Seat Tube Length (inch) | 15.7 | 16.7 | 17.7 | 18.7 |
| B | Seat Tube Angle | 76.0° | 76.0° | 76.0° | 76.0° |
| C | Top Tube Length (inch) | 22.8 | 23.9 | 25.2 | 26.4 |
| D | Head Tube Length (inch) | 4.1 | 4.5 | 4.9 | 5.3 |
| E | Head Tube Angle | 65.5° | 65.5° | 65.5° | 65.5° |
| F | Fork Rake (inch) | 1.7 | 1.7 | 1.7 | 1.7 |
| G | Trail (inch) | 4.9 | 4.9 | 4.9 | 4.9 |
| H | Wheelbase (inch) | 47.4 | 48.5 | 49.9 | 51.2 |
| I | Chain Stay Length (inch) | 18.4 | 18.4 | 18.4 | 18.4 |
| J | Bottom Bracket Drop (inch) | 1.6 | 1.6 | 1.6 | 1.6 |
| K | Stack (inch) | 24.3 | 24.7 | 25 | 25.4 |
| L | Reach (inch) | 16.7 | 17.7 | 18.9 | 20.1 |
| M | Stand Over Height (inch) | 29.9 | 29.9 | 30.7 | 31.3 |
| N | Handlebar Width (inch) | 30.7 | 30.7 | 30.7 | 30.7 |
| O | Stem Length (inch) | 1.6 | 1.6 | 2 | 2 |
| P | Crank Length (inch) | 6.5 | 6.5 | 6.5 | 6.5 |
| Q | Wheel Size | 29" | 29" | 29" | 29" |
SPECIFICATIONS
| Motor | Giant SyncDrive Sport2, 75Nm, PedalPlus 6-sensor technology |
| Controller | Giant RideControl App enabled ANT+ wireless display signal with e-bike profile |
| Display | Giant RideControl Dash, high-angle visibility, full color LCD display |
| Battery | Giant EnergyPak 500Wh, Aluminium casing with highest safety standard (EN50604), CO2 Neutral production, Giant EnergyPak Plus 250 range extender compatible |
| Charger | Giant EnergyPak 4A smart charger compact, 60% charge in 2:00h |
| Sizes | S, M, L, XL |
| Colours |
Black Diamond
|
| Frame | ALUXX SL-grade aluminum, 1.5"~1.8" head tube,125mm travel FlexPoint suspension system, 'Boost' 148x12 UDH rear axle, EnergyPak Plus Range Extender Compatible |
| Fork |
SR Suntour XCR 34 LO-R, 140mm travel, tapered steerer, Lockout, 110x15 thru-axle
|
| Shock | SR Suntour Raidon R, 190x45mm, recommended sag: 30% |
| Handlebar |
Giant Connect TR Riser 31.8x780mm
|
| Grips |
Giant Tactal single lock-on
|
| Stem | Giant Contact |
| Seatpost | Giant 30.9mm, 2-bolt Micro Adjustable, Forged Aluminium |
| Saddle | Giant Sport |
| Pedals | N/A |
| Shifters | Shimano Deore LinkGlide |
| Front Derailleur | MRP HD2 co-moulded chain guide |
| Rear Derailleur | Shimano Deore LinkGlide, 10-speed |
| Brakes | Tektro HD-M745 Orion, 4-piston, hydraulic disc, 203mm |
| Brake Levers |
Tektro HD-M745 Orion
|
| Cassette | Shimano LinkGlide, CS-LG400-10, 11-43T, 10-speed |
| Chain | Shimano, LinkGlide, CN-LG500 |
| Crankset | FSA Comet E-Bike crank arm set FSA MegaTooth Direct-mount 1X steel 36T |
| Bottom Bracket | n/a |
| Rims | Giant AM30, Tubeless ready, 30mm inner width, 29" |
| Hubs | Giant eTracker Boost, [F] 110x15 [R] 148x12mm |
| Spokes | Stainless Steel |
| Tires |
Maxxis Minion DHF 29X2.50" Foldable, TLR, EXO, 60TPI [F]Maxxis Dissector 29X2.40" WT Foldable, TLR, EXO, 60TPI [R]
|
| Extras | - |
| Lighting |
-
|
| Lock | Torx 25 Battery Lock with built-in Torque limiter |
| Carrier | - |
| Weight | The most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality. |
