| Article number: | 1083012195-STM-M |
| Availability: | In stock |
FEATURES
 |
 |
ALUXX Aluminum TechnologyThis Performance level frame material features 6061 alloy with single-butted tubes to produce strong, lightweight framesets for a variety of different bikes and riding style |
D-Fuse SeatpostThe proprietary “D” shaped composite seatpost damps vibration, resulting in a smooth, compliant ride. |
SIZE GUIDE
Sizing to be used as a reference only. Please check with a local authorized dealer to determine the correct size.
Available sizes may vary from country to country.
| Sizes | Height |
| XS | 4'10" - 5'4" |
| S | 5'2" - 5'7" |
| M | 5'5 - 5'9" |
| L | 5'7" - 6'0" |
GEOMETRY
| XS | S | M | L | ||
|---|---|---|---|---|---|
| A | Seat Tube Length (inch) | 15 | 16.5 | 18.1 | 19.7 |
| B | Seat Tube Angle | 74.0° | 73.5° | 73.0° | 73.0° |
| C | Top Tube Length (inch) | 21.7 | 22.4 | 23.2 | 24 |
| D | Head Tube Length (inch) | 4.3 | 4.7 | 5.3 | 5.9 |
| E | Head Tube Angle | 70.5° | 70.5° | 70.5° | 70.5° |
| F | Fork Rake (inch) | 1.7 | 1.7 | 1.7 | 1.7 |
| G | Trail (inch) | 3.3 | 3.3 | 3.3 | 3.3 |
| H | Wheelbase (inch) | 41.7 | 42.3 | 42.9 | 43.7 |
| I | Chain Stay Length (inch) | 17.7 | 17.7 | 17.7 | 17.7 |
| J | Bottom Bracket Drop (inch) | 2.4 | 2.4 | 2.4 | 2.4 |
| K | Stack (inch) | 23.7 | 24.1 | 24.6 | 25.2 |
| L | Reach (inch) | 14.9 | 15.3 | 15.7 | 16.3 |
| M | Stand Over Height (inch) | 23.2 | 23.9 | 24.4 | 24.8 |
| N | Handlebar Width (inch) | 25.2 | 25.2 | 26.8 | 26.8 |
| O | Stem Length (inch) | 2.8 | 3.1 | 3.1 | 3.5 |
| P | Crank Length (inch) | 6.5 | 6.7 | 6.7 | 6.9 |
| Q | Wheel Size | 700C | 700C | 700C | 700C |
SPECIFICATIONS
| Sizes | XS, S, M, L |
| Colours | Storm Cloud |
| Frame | ALUXX-grade aluminum, disc |
|
Fork
|
SR Suntour NEX HLO 700C, 63mm, disc, lockout without rebound |
| Shock |
N/A
|
| Handlebar | Giant Connect XC, 31.8mm, 9-degree/6-degree rise XS: 640mm, S: 640mm, M: 680mm, L: 680mm |
| Grips | Liv ErgoContact |
| Stem | Giant Sport XS: 70mm, S: 80mm, M: 80mm, L: 90mm |
| Seatpost | Giant D-Fuse, alloy XS: 300mm, S: 300mm, M: 300mm, L: 350mm |
| Saddle | Liv Ergo Contact |
| Pedals | platform |
| Shifters | Shimano CUES, 2x10 |
| Front Derailleur | Shimano CUES |
| Rear Derailleur | Shimano CUES |
| Brakes | Tektro TKD143, hydraulic disc [F]160mm, [R]160mm |
| Brake Levers | Tektro TKD149 |
| Cassette | Shimano CSLG40010D, 11x39 |
| Chain | KMC X11 with Missing Link |
| Crankset | Shimano CUES, forged alloy, 30/46 XS: 170mm, S: 170mm, M: 170mm, L: 170mm |
| Bottom Bracket | threaded |
| Rims | Giant SX Disc |
| Hubs | alloy, 28h |
| Spokes | stainless steel, 14g |
| Tires |
Giant CrossCut, 700x42c, puncture protect
|
| Extras | 55c max tire size without fender, 45c max tire size with fender, reflective stickers, kickstand, fender and rack frame mounts |
| Weight | The most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality. |
